Blue Sea - ST Blade Fuse Block Kit

We offer two versions of the Blue Sea ST Blade Battery Terminal Mount Fuse Block.

The 5023 kit contains a positive fuse block.

The 5024 kit contains both a positive fuse block and a negative ¢‚¬ËœBus¢‚¬„¢ block.

Features:

• Circuits: 4
• Maximum Amperage: 30A per circuit (100A per block)
• Maximum Voltage 32V DC
• Easy to install 4 ATO‚®/ATC‚® fused circuits
• Mounts directly on the battery terminal studs
• Screw terminals for securing wires
• Nylon insulated ring terminals included
• Insulating covers included
• Accepts Small Format Circuit Labels included.
• Includes 1 x 15amp blade fuse

The Blue Sea Terminal Mount Fuse Block is an easy and convenient way to create four separate fused power supplies to your 12v accessories without having to wire in separate inline fuses or use a remote mounted fuse-block. The use of the Terminal Mount Fuse block keeps the fuses in their optimum location as close to the battery as possible.

The Blue Sea Terminal Mount Fuse Block has an M10 fixing tab designed for attaching directly to the post of the battery. This makes it especially useful on the later ¢‚¬ËœPuma¢‚¬„¢ (2.2/2.4Tdci) Defender that have the separate threaded M8 bolt hole on the positive battery terminal or any aftermarket performance battery equipped with spare positive posts.
