OME - Volkswagen Amarok Air Bag Kit For Parabolic Springs - (2022-2025)

The OME Air Bag has been designed with an all-new internal bump stop. Whilst replacing the OE bump stop that is removed during installation, this internal bump stop allows the Air Bag to be used unpressurised so you can drive on it empty and inflate it only when you need it.
An Air Bag with even 4psi in it and no additional load added can disrupt the ride comfort of the vehicle and this is where the ARB Air Bag surpasses the others.
Venting the Air Bag is achieved by a specifically designed Purge Control system which can be controlled manually with the valve tap or via the all-new standalone ARB Air Bag Control system and the market leading LINX Air Bag Control module

Included in the Air Bag kit is:

• 2x OME Air Bags
• Vehicles specific mounting brackets
• 2x Air Lines
• 2x Inflation valves (Schrader type)
• 2x Purge valves
• Exhaust heat shield
• Air fittings
• Vent filters
• Comprehensive fitting instructions
• 2 Inflation warning sticker for:
  • Driver door jam
  • Manual inflation valve bracket


INFLATING THE AIR BAG
There are three ways of inflating and deflating the Air Bags in this kit:

1. Manually via the Schrader inflation valves including with every Air Bag Kit
   • Can be inflated with any compressed air source such as your mountable or portable ARB Air Compressor or using the tyre inflator at a petrol station. Uses the manual Purge Valve Tap included in the kit to purge or hold air
2. Electronically via the all-new ARB Air Suspension Control (part no. 0830002)
   • Inflation and deflation control in the palm of your hands via a smart phone app
   • Uses a pressure regulating valve, isolation valves and an ECU permanently connected to your mounted ARB Air Compressor, then controlled by the smart phone app
   • Use the Air Bag Purge Control Kit (part no. OMEABK001) to have electronic control of the purge function also
3. Electronically via the market leading ARB LINX Vehicle Accessory Interface (part no. LX100)
   • Complete inflation and deflation control from a dedicated vehicle accessory interface mounted on the a-pillar, inside the vehicle
   • Uses a pressure regulating valve, isolation valves and the LINX ECU permanently connected to your mounted ARB Air Compressor for truly integrated control
   • Use the Air Bag Purge Control Kit (part no. OMEABK001) to have electronic control of the purge function also
